         公司系专业生产XPS/挤塑保温隔热板设备的私营股份企业,也是首家针对严寒地区生产XPS设备研制企业,经过科研人员的不懈努力,设备已达到并部分超越了国内外先进水平。公司以“保姆式”的服务提供整套生产线及生产工艺,包括机器安装、调试、人员培训,并承诺所生产的产品完全符合国家GB/T1084-2(绝热用挤塑聚苯乙烯泡沫塑料)中的检测要求。

    公司在消化、吸收国外引进的XPS挤塑聚苯乙烯保温板生产线的基础上,根据我国的国情进一步改进、提高,通过价值性能比的分析,简化了工艺流程,改变了螺杆的模具设计,提高生产线的加工能力和增加了产品的规格。电动机的功率由135\120千瓦逐步降为75\45千瓦,单位产品的能耗降低了近一半;原材料的使用由必须使用全新的聚苯乙烯颗粒到可以全部使用回收的再生聚苯乙烯颗粒,降低了产品的成本、节约了能源,并有效地解决了困扰每个国家的“白色污染”问题、美化了环境。生产线半自动化的设计使设备地操作更简易,并大幅度降低了设备的操作、维护、维修成本。敝公司坚持技术开发和技术进步,随着市场的普及和需求的不断提升,我们还在努力研发比目前更先进、更安全、更节能的生产线,并免费为老客户升级设备-----只收“工本费”。该项目经济效益好,投资少,加上节能和使用废料,使生产XPS节能保温板的价格仅是国外同类产品的三分之一至四分之一,使XPS保温板在建筑保温和高寒地区道路隔水防冻等领域得到大规模的推广应用,使产品在市场上供不应求。

XPS Foamed Board production Line Application & Feature:

XPS foamed sheet, also named as Polystyrene Extrusion Plastic Sheet (XPS for short) has a perfect closed-pore structure. Its density, water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower than those of other sheet heat insulating materials and they have the characteristics of strong intensity, light material, airtight, anticorrosion, ageing resistance, low cost, etc. It has been widely used in the fields of heat preservation in the construction industry and the highway, railway, airport, square of the heat preservation and household fitment. It is the generally acknowledged and the best heat insulator in the market at present.

It is used in steel construction workshop, iron sheet house and colored ripple tile for heat preservation.

It is used for making up the heat insulation board in the refrigeration storehouse for cold preservation and waterproofing.

It is used for laying the bedding under the road bed of the highway for buffering and controlling the frost heaving of the ground.

It is used for waterproofing and heat preservation of residential building, office building, the factory wall and roof.

It is used for laying the bedding under the floor for the function of heat insulation, damp proof and sound insulation.

It is used in the ventilation piping of central air conditioner for heat insulation and heat preservation

XPS Foamed Board production Line parameters:
Extruder system               No 1 zone              No 2 zone
Screw Dia (mm)                      120                    150
Screw ratio(L/D)                      31                      36
Center Height(mm)                1050
Heating zone                          9                       12
Heating power(kw)                 70                       80
Drawing motor power(kw)       75                       45
Thickness of produced board(mm)    20-100
Width of produced board(mm)      600, 900 -1200
Length of produced board(mm) 1200, 1250, 2450, 2500
Output(m3/24h)                       200
Total weight (ton)                      24

Sell Offer [XPS Foamed Board Production Line]
We are specializing in producing XPS Foamed Board Production Line and export to Russia, Southeast Asia etc.  Extruder system No 1 zone No 2 zone Screw dia (mm) 120 150 Screw ratio(L/D)31 36 Heating power(kw) 70 80  Driving motor power(kw) 75 45  Thickness of produced board(mm)20-100 Width of produced board(mm)600,900,1200 Length of produced board(mm) 1200,1250,2450,2500 Output(m3/24h)200  Total weight (ton) 24.
Company:- Beijing Plastic Mach. Co., Ltd
City:- Beijing  State:- Beijing  Country:- China
Mobile:86-13693236069
Phone:- 86- 10-86714939 (14-16p.m. only)
Email:-
jy4939@hotmail.com
